Features
Small size, light weight.
Low coil consumption.
PC board mounting.
Suitable for household electrical appliances, automation system, electronic equipment, instrument, meter, telecommunication facilities and remote control facilities.
Ordering Information
1. Part number: NT78
2. Contact arrangement: A:1A B:1B C:1C U:1U
3. Enclosure: S: Wash tight NIL: Flux proof
4. Coil power: 0.6:0.6W 0.8:0.8W
5. Coil rated voltage(V): DC:6,9,12,24
| Insulation Resistance | 100MΩ min (at 500VDC) | ltem 4.11 of lEC 61810-7 |
| Dielectric Strength | 50Hz 500V | ltem 4.9 of lEC 61810-7 |
| Between Contacts | 50Hz 500V | ltem 4.9 of lEC 61810-7 |
| Between Contact and Coil | 50Hz 500V | ltem 4.9 of lEC 61810-7 |
| Shock Resistance | 98m/s2 11ms | ltem 4.26 of IEC 61810-7 |
| Vibration Resistance | 10Hz~55Hz Double amplitude 1.5mm | ltem 4.28 of IEC 61810-7 |
| Terminals Strength | 10N | ltem 4.24 of IEC 61810-7 |
| Ambient Temperature | -40℃~85℃ | ltem 4.24 of IEC 61810-7 |
| Relative Humidity | 5% to 85% | ltem 4.16 of IEC 61810-7 |
| Mass | 6g | ltem 4.7 of IEC 61810-7 |
